4-6 Cabling a High-Speed Network Module

HN4000 Hardware Installation Guide 920550-5020 Rev 14

Takethefollowingstepstoinstallthecabling.

Step 1. Attachtheright‐anglemini‐BNCcableend(male)ofanadaptercabletoeachofthe

module’sports(TXandRX).

Step 2. DresstheadaptercablestotherightoftheHN4000andthroughacable‐guideslotin

theright‐

sidemountingbracket.

Step 3. Attachthefacility’sBNCcablestoadaptercable’sBNCconnectors.

Step 4. Terminatetheotherendofthecablespercustomerrequirements.

End of Procedure
