Power and Ground Requirements 1-9
920550-5020 Rev 14 HN4000 Hardware Installation Guide
1.7 Power and Ground Requirements
1.7.1 Power Budget
ThepowersourcefeedinganHN4000mustprovideanominal‐48VDCat2Amperes.
DCvoltageMin/Maxis‐40.0to‐57.6VDC,measuredatthechassis.
A2Amperefuseratingisrecommended.
1.7.2 Power Requirements
TherackfortheinstallationoftheHN4000mustbeequippedwithacircuitbreakerpanelor
fusepanel.Iftherackdoesnothaveacircuitbreakerpanelorfusepanel,onemustbeaccessi
blewithinacablingdistanceof15feet(4.5m)ofthepowerinputsonthe
HN4000chassis.
TheHN4000mustbeconnectedtoagroundedSafetyExtraLowVoltage(SELV)source.The
SELVsourceisdefinedasDCvoltagesratedunder60VDC.Refertothesection”Installingthe
GroundandPowerCables”onpage26forinstallationinformation.
1.7.3 Grounding Requirements
TheHN4000chassisisequippedwithadoubleholecrimpedterminal.Groundingoftheraw
endofthecableshouldconformwithlocalpractices,usingwiresizesof
1014AWG(1.62.6mm).
Refertothesection”InstallingtheGroundandPowerCables” on page 26forinstallation
information.
1.8 Required Tools
ThefollowingtoolsarerequiredforanHN4000installation:
Note
The DC return is to remain isolated from the system frame and the chassis (DC-I).
Caution
The HN4000 must be permanently grounded to a Common Bonding Network (CBN).
Tools
#1,#2,and#3Phillipsscrewdrivers
1/8inchflatbladescrewdriver
3/8inchhexnutdriverorratchet/socketcombination
Cabletiecutters
Crimperfor#1014AWGlug
