2-4 Installing the Rack Mounting Brackets
HN4000 Hardware Installation Guide 920550-5020 Rev 14
2.4.2 Mounting Brackets and Hardware
TheHN4000bracketassembliesandmountinghardwarearepackagedintheshelf/rack
mountingkitsshowninFigure 23.Fromlefttoright,thekitsarefor19”ANSI,23”ANSI,
andETSI.TheappropriatemountingkitisprovidedwiththeHN4000,basedonthemounting
specifiedwhentheHN4000was
ordered.
Figure 2-3 Bracket Assemblies and Hardware
Thecontentsofthekitsare:
1. 19”ANSIrackmountingamountingkitwithtwobrackets,eight#632bracketscrews,
four#1224rackscrews,andfour#12externaltoothlockwashers(shownattheleftsideof
Figure 23).
2. 23”ANSIrackmountingthecontentsof
the19”ANSIrackmountingkit(described
above),plustwo23”ANSIextenderbrackets,four#1224rackscrews,andfour#12exter
naltoothlockwashers.ThekitisshowninthecenterofFigure 23.)Notethatthefour
screwsandwashersfortheextenderbracketsarepackaged
inthe19”ANSIkit’shardware
bag.The23”ANSImountingkitisprovidedifnomountingtypeisspecifiedwhenan
HN4000isordered.
3. 600mmwideETSIrack/cabinetmountingamountingkitwitheight#632bracket
screws,fourM6rackscrews,andfourM6externaltoothlock
washers(shownattheright
sideofFigure 23).
19” ANSI Mounting Hardware 23” ANSI Mounting Hardware 600 mm ETSI Mounting Hardware
