5-2 Prerequisites
HN4000 Hardware Installation Guide 920550-5020 Rev 14
5.1 Prerequisites
BeforestartingtheprocedurestoinstalltheHN4000systemsoftware,thefollowingstepsmust
havebeencompleted:
HN4000installedasdescribedinChapter2
powerandnetworkcablesinstalledasdescribedinChapter4
HN4000poweredupandallLEDsinthe“ready”stateasdescribedinChapter2
HN4000systemsoftwareloadedonanFTPserverthatisonanetworkthatcanbeaccessed
fromtheHN4000
optionally,accesstoaDHCPserver
5.2 Loading System Software using DHCP
ThegeneralstepsforusingtheDHCPoption,describedinthefollowingsections,areto:
connectnetworkcablingfromaDHCPservertotheHN400010/100managementport
connectaconsolemaintenanceterminaltotheHN4000craftport
usetheCLItoenableDHCPontheHN400010/100managementport
initiatethesoftwaredownloadprocesswiththecopyswImagecommand
verifythatthesystemsoftwarehasbeendownloaded
Note
The following steps assume that Network Operations Center (NOC) personnel will configure the
DHCP server and load the HN4000 system software onto an FTP server. Those steps are sum-
marized in the section ”Setting up FTP and DHCP Servers (For Network
Administrators)” on page 5-9.
