Hatteras HN4000 User Manual

Cabling a High-Speed Network Module 4-3
920550-5020 Rev 14 HN4000 Hardware Installation Guide
4.2 Cabling a High-Speed Network Module
TheHN4000supportsthehigh‐speednetworkmodulesshowninFigure 4‐3anddescribedin
Table4‐1.
Figure 4-3 High-Speed Network Modules
Table 4-1 HN4000 High-Speed Module Model Numbers
Item Description Model Number
ModulesforHN4000
UniversalI/OSlot
•Dual100/1000BASE‐TEthernetports HN4000‐GbT
•Dual1000BASE‐Xsmallform‐factorpluggable(SFP)Ethernetports HN4000‐GbX
•Dual100BASE‐Xsmallform‐factorpluggable(SFP)Ethernetports HN4000‐FEX
•UnchannelizedT3/E3‐TXportsupportingx.86andGFP HN4000‐TE3
