4-2 Cabling the 10/100 Management Port
HN4000 Hardware Installation Guide 920550-5020 Rev 14
4.1 Cabling the 10/100 Management Port
PerformthefollowingstepstoconnectaCAT‐5cabletothe10/100MGMTport.
Step 1. PlugtheRJ‐45connectoroftheCAT‐5cableintotheHN4000portlabeled“10/100
MGMT”(Figure 4‐2).
Figure 4-2 10/100BaseTX Management Connector
Step 2. DresstheEthernetcabletotherightoftheHN4000andthroughacable‐guideslotin
theright‐sidemountingbracket.
Step 3. Terminatetheotherendofthe10/100BaseTXEthernetCablepercustomerrequire‐
ments.
End of Procedure
Cabling to the 10/100 management port is optional, depending on how the HN4000 will be
managed.
The “10/100 MGMT” port on the HN4000
is cabled to a customer Data Communication Network
(DCN). If the customer does not have a DCN then the “10/100 MGMT” port is not cabled.
Static Electricity can damage or decrease the reliability of electrical and optical equipment. While
unpacking and handling electrical and optical equipment, wear a grounding wrist strap to dis-
charge the static buildup. The grounding wrist strap is designed to prevent equipment damage
caused by static electricity. Before unpacking and installing equipment or making system intercon-
nections, connect the grounding wrist strap.
