131
8.6 Message Reference
Set and Query Comparator Settings
Comparator State
Syntax
Command
Query
Response
:CALCulate:LIMit:STATe <1, 0, ON or OFF>
:CALCulate:LIMit:STATe?
<ON or OFF>
Example
Command
:CALC:LIM:STAT ON
Beeper State
Syntax
Command
Query
Response
:CALCulate:LIMit:BEEPer <OFF, HL or IN>
:CALCulate:LIMit:BEEPer?
<OFF, HL or IN>
Example
Command
:CALC:LIM:BEEP HL
Note
The following HIOKI 3227 command can be used, but the format of the response
message is different.
:CSET:BEEPer
Decision Mode Setting
Syntax
Command
Query
Response
:CALCulate:LIMit:MODE <HL or REF>
:CALCulate:LIMit:MODE?
<HL or REF>
HL = Decision by preset upper and lower thresholds.
REF = Decision by a reference value and tolerance.
Example
Command
:CALC:LIM:MODE REF
Note
The following HIOKI 3227 command can be used, but the format of the response
message is different.
:CSET:CMODe
Upper Threshold Setting
Syntax
Command
Query
Response
:CALCulate:LIMit:UPPer <Upper threshold>
:CALCulate:LIMit:UPPer?
<Upper threshold>
<Upper threshold> = 0 to 999999 (NR1)
Example
Command
:CALC:LIM:UPP 005971
Lower Threshold Setting
Syntax
Command
Query
Response
:CALCulate:LIMit:LOWer <Lower threshold>
:CALCulate:LIMit:LOWer?
<Lower threshold>
<Lower threshold> = 0 to 999999 (NR1)
Note
(For both Upper
and Lower
thresholds)
• Upper and Lower thresholds are specified as integer values. To specify 0.567 Ω
in the 2Ω range, send the following command:
:CALCulate:LIMit:UPPer 56700 (or 056700)
• The following HIOKI 3227 command can be used, but the format of the
response message is different.
:CSET:PARAmeter
