8.2 Displaying the Event List
142
Select an event to display detailed event information and multiple event parameters.
Displaying event details
Select the event
type in the detail
display
Move the yellow
cursor to select an
event
The voltage waveform
when the event occurred
is shown.
You can more the yellow cur-
sor up and down 100 rows at
a time with the F1 and F2
keys.
You can move the cursor to the most
recent event with the F4 key.
