8.2 Displaying the Event List
143
Chapter 8 Checking Events (EVENT screen)
8
Event items, list notation, and saved items
Event items
Event list
no
tation
IN/OUT/
SENSE
Synchronized save items
Measurement items
Event
waveform
High-speed
waveform
Fluctuation
data
Transient overvoltage Tran IN/OUT
All instantaneous values
Frequency, voltage, cur-
rent, power, power factor,
unbalance factor
, harmonic
voltage, harmonic current,
harmonic power, harmonic
voltage distortion factor,
harmonic current distortion
factor, K factor, high-order
harmonic voltage compo-
nent and current compo-
nent.
(Event category)
Transient over-
voltage waveform
Swell Swell IN/OUT
Dip Dip IN/OUT
Interruption Intrpt IN/OUT
Inrush current
Inrush
(Irms1/2)
IN/OUT
Frequency 200 ms Freq IN/OUT
Frequency cycle Freq_wav IN/OUT
Voltage waveform
peak
Upk IN/OUT
RMS voltage Urms IN/OUT/SENSE
Voltage DC change
(CH4 only)
Upp IN/OUT
Current waveform
peak
Ipk IN/OUT
RMS current Irms IN/OUT/SENSE
Current DC change
(CH4 only)
Ipp IN/OUT
Active power P IN/OUT
Apparent power S IN/OUT
Reactive power Q IN/OUT
Power factor/
displacement factor
PF IN/OUT
Voltage
negative-phase
unbalance factor
Uunb IN/OUT
Voltage zero-phase
unbalance factor
Uunb0 IN/OUT
Current
negative-phase
unbalance factor
Iunb IN/OUT
Current zero-phase
unbalance factor
Iunb0 IN/OUT
Harmonic voltage Uharm IN/OUT
Harmonic current Iharm IN/OUT
Harmonic power Pharm IN/OUT
Phase difference of
harmonic voltage and
harmonic current
Pphase IN/OUT
Total harmonic volt-
age distortion factor
Uthd IN/OUT
Total harmonic current
distortion factor
Ithd IN/OUT
K factor KF IN/OUT
High-order harmonic
voltage component
UharmH IN/OUT
High-order har-
monic waveform
High-order harmonic
current component
IharmH IN/OUT
High-order har-
monic waveform
Voltage waveform
comparison
Wave
Timer event Timer
Continuous event Cont
External event Ext
Manual event Manu
Start Start
Stop Stop
GPS
Note 1
GPS_IN
GPS_OUT
GPS_Err
