Hioki PW3360-21 - Enlarging Measured Values on the Display

5.11 Enlarging Measured Values on the Display
97
Chapter 5 Viewing Measurement Data
5
Press the or [SCREEN] key to display the [MEAS, ZOOM] screen.
Changing display parameters
5.11 Enlarging Measured Values on the Display
Selects the parameter 
to enlarge.
1
Press the [SELECT] key.
The cursor will move to the display parameter field, and you will be able to
change the setting.
2
Using the cursor keys, move to
the parameter whose enlarged
display you wish to change and
press the [ENTER] key.
A dialog box for selecting the en-
larged display will be displayed.
3
Select the desired parameter with the cursor keys and accept the new
setting with the [ENTER] key.
Change other parameters similarly.
4
Press the [SELECT] key to cancel the setting process.
Display of selection position
of the scrolling parameter
On the expanded display, you cannot select demand or harmonic
parameters.
