12.3 Detailed Measurement Specifications
182
Measurement items
12.3 Detailed Measurement Specifications
Voltage RMS (U)
Measurement
method
True RMS type
Measurement
range
600 V single range
Measurement
accuracy
45 Hz to 66 Hz: ±0.3% rdg. ±0.1% f.s.
With a fundamental frequency of 50/60 Hz
Up to 1 kHz: ±3% rdg. ±0.2% f.s.
Up to 3 kHz: ±10% rdg. ±0.2% f.s.
With 3P3W3M wirings, add ±0.5% rdg.
Current RMS (I)
Measurement
method
True RMS type
Measurement
range
Load current
Model 9660, 9695-03 (1mV/A) : 5.0000/10.000/50.000/100.00 A
Model 9661 (1mV/A) : 5.0000/10.000/50.000/100.00/500.00 A
Model 9669 (0.5mV/A) : 100.00/200.00/1.0000k A
Model 9694 (10mV/A) :
500.00m/1.0000/5.0000/10.000/50.000 A
Model 9695-02 (10mV/A) : 500.00m/1.0000/5.0000/10.000/50.000 A
Model CT9667 500A range (1mV/A) : 50.000/100.00/500.00 A
Model CT9667 5000A range (0.1mV/A) : 500.00/1.0000 k/5.0000k A
Leakage current
Model 9657-10, 9675 (100mV/A): 
50.000m/100.00m/500.00m/1.0000/5.0000 A
Range control Manual range
Measurement
accuracy
45 Hz to 66 Hz: ±0.3% rdg. ±0.1% f.s. + clamp sensor specifications
With a fundamental frequency of 50/60 Hz
Up to 1 kHz: ±3% rdg. ±0.2% f.s. + clamp
sensor specifications
Up to 3 kHz: ±10% rdg. ±0.2% f.s. + cla
mp sensor specifications
