8.2 Folder and File Structure
120
Only settings files and recording and measurement data files can
be saved in the instrument’s internal memory. Since harmonic
measurement data (PW3360-21 only), screen copies, and wave-
form data cannot be saved in internal memory, they must be saved
o
n
the SD memory card.
Internal Memory
Manual folder and file naming setting (for ex-
ample, “HIOKI”)
Internal memory root folder
Setting file
(.SET)
Recording and
measurement
file
(.CSV)
60SETXX.SET
60MEMXX.CSV
HIOKI.CSV
HIOKIXX.CSV
60BACKXX.CSV
(XX: 00 to 99)
Automatic folder and file naming setting
If recording is stopped and then restarted using
the manual “HIOKI” setting
Data that was backed up in the internal memory
because no SD memory card was inserted
when the save destination was set to [SD
CARD]
When recording and measurement are
stopped, if an SD memory card has been insert-
ed into the instrument, data will be moved from
the instrument’s internal memory to the SD
card’s recording and measurement data file.
