Hioki PW3360-21 - When the 9694 or 9695-02 Is Used (CAT III, 300 V); When the CT9667 Is Used

12.6 Range Configuration and Accuracy by Clamp Sensor
212
*Accuracy is guaranteed for 500 mA to 5 A ranges (9694) and for 500 mA to 50 A ranges (Model
9695-02).
When the 9694 or 9695-02 is used (CAT III, 300 V)
Power ranges
Voltage Wiring
Current range
500.00 mA 1.0000 A 5.0000 A 10.000 A 50.000 A
600.00 V
1P2W 300.00W 600.00W 3.0000kW 6.0000kW 30.000kW
1P3W
1P3W1U
3P3W2M
3P3W3M
600.00W 1.2000kW 6.0000kW 12.000kW 60.000kW
3P4W 900.00W 1.8000kW 9.0000kW 18.000kW 90.000kW
Combined accuracy
Current range Model 9694 sensor Model 9695-02 sensor
50.000 A - ±0.6%rdg.±0.12%f.s.
10.000 A - ±0.6%rdg.±0.2%f.s.
5.0000 A ±0.6%rdg.±0.12%f.s. ±0.6%rdg.±0.3%f.s.
1.0000 A ±0.6%rdg.±0.2%f.s. ±0.6%rdg.±1.1%f.s.
500.00 mA ±0.6%rdg.±0.3%f.s. ±0.6%rdg.±2.1%f.s.
When the CT9667 is Used
Power ranges
Voltage Wiring
500A range 5000A range
50.000 A 100.00 A 500.00 A 500.00 A 1.0000 kA 5.0000 kA
600.00 V
1P2W 30.000 kW 100.00 A 300.00kW 300.00 kW 600.00 kW 3.0000MW
1P3W
1P3W1U
3P3W2M
3P3W3M
60.000 kW 120.00 kW 600.00kW 600.00 kW
1.2000 MW 6.0000MW
3P4W 90.000 kW 180.00 kW 900.00kW 900.00 kW
1.8000 MW 9.0000MW
Combined accuracy
Current range
Model CT9667 sensor
5000A range
Model CT9667 sensor
500A range
5.0000 kA ±2.3%rdg.±0.4%f.s. －
1.0000 kA ±2.3%rdg.±1.6%f.s. －
500.00 A ±2.3%rdg.±3.1%f.s. ±2.3%rdg.±0.4%f.s.
100.00 A － ±2.3%rdg.±1.6%f.s.
500.00 A － ±2.3%rdg.±3.1%f.s.
