5.1 Viewing and Using the Measurement Screen
83
Chapter 5 Viewing Measurement Data
5
The PW3360 allows you to view measured values, waveforms, and graphs on the
Measurement screen.
Viewing Measurement 
Data
Chapter 5
5.1 Viewing and Using the Measurement Screen
Holds measured values. While values are being
held, the HOLD indicator will turn red.
Allows you to select a Measurement screen.
Selects a
screen name
from a list.
Enter
Switches to the Measurement
screen and changes the Mea-
surement screen.
Current channel
Current rangeClamp sensor
• If a setting is changed while measured values are being held, the
hold will be canceled.
• The time display is not fixed while measured values are being
held.
