2.1 Preparation Flowchart
21
3
2
Chapter 2 Measurement Preparations
Before starting measurement, connect accessories and options to the instrument.
Before performing measurement, be sure to inspect the instrument as well as any
accessories and options for possible malfunctions.
Follow the procedure described below to prepare for measurement.
Measurement 
Preparations
Chapter 2
2.1 Preparation Flowchart
(At purchase)
(At purchase)
Wrap the color spiral tubes
around the clamp sensor cables.
(p. 23)
2
Connect the AC adapter.
(p. 33)
Insert an SD memory card.
(p. 30)
6
7
3
8
Secure the voltage cords to-
gether with a spiral tube.
(p. 22)
1
(At purchase)
Install the battery
pack. (p. 24)
Turn on the instrument. (p. 38)
Perform the pre-measurement 
inspection. (p. 29)
5
Set the language and measure-
ment line frequency
(p. 28)
4
(At purchase)
