8.1 Viewing and Using the File Screen
114
SD memory card file screen
8.1 Viewing and Using the File Screen
Displays the File screen (SD
memory card/internal memory)
and switches screens.
Displays the amount of space used
on the SD memory card.
Displays the current display location. In this case, the screen is
displaying the PW3360 folder on the SD memory card.
When you scroll the screen with the cursor
keys, the scroll bar indicates your current position.
Displays a folder and file list. The list order reflects the order in the save area on the SD
memory card.
: Move within the folder hierarchy (select folders and files).
: Move up and down.
or
: Folder
: File
Function keys Reference
USB Drive 10.1, "Copying Data to a Computer (USB)" (p. 148)
SET.LOAD 8.5, "Loading Settings Files" (p. 123)
DELETE 8.7, "Deleting Folders and Files" (p. 126)
FORMAT
8.8, "Formatting the SD Memory Card or Internal
Memory" (p. 127)
• The File screen can display folder and file names of up to eight
byte characters in length (or four double-byte characters). Lon
-
ger names are truncated and displayed. 
Example: Filename: 1234567890
Display on File screen: 123456~X (X: number)
• Up to 204 folders and files can be displayed. Folders and files in
excess of tha
t number will not be shown.
