9.3 Checking Recording and Measurement Data with Excel
138
Measurement information
Parameter
Parameter
name
Format Description
Date
Output time
an
d date
YYY
Y-MM-DD
hh:mm:ss
Output time and date
Etime Elapsed time hhhh:mm:ss Elapsed time from start of recording
Status
Measurement
Inform
ation
HGFEDCBA
(A to H: 0 or 1)
A : U1 (voltage CH1) peak exceeded
B : U2 (voltage CH2) peak exceeded
C : U3 (voltage CH3) peak exceeded
D : I1 (current CH1) peak exceeded
E : I2 (current CH2) peak exceeded
F : I3 (current CH3) peak exceeded
G : Frequency error
H : Power outage during interval time
Example:
If data includes I1 (current CH1) data in
exce
ss of peak: 00001000
