9.3 Checking Recording and Measurement Data with Excel
141
3
Chapter 9 Analyzing Data on a Computer
9
Q1_xxx[var] Reactive power Q1(CH1)
Q2_xxx[var] Q2(CH2)
Q3_xxx[var] Q3(CH3)
Q_xxx[var] Q(total)
PF1_xxx Power factor PF1(CH1)
See: "PF/Q/S calculation"
(p. 66)
"Appendix4 Termi-
nology" (p. A6)
PF2_xxx PF2(CH2)
PF3_xxx PF3(CH3)
PF_xxx PF(total)
DPF1_xxx
Displacement power factor
DPF1(CH1)
DPF2_xxx DPF2(CH2)
DPF3_xxx DPF3(CH3)
DPF_xxx DPF(total)
WP+[Wh] Active energy (Consumption)
Active energy from start
of recording (Consump-
tion)
WP+1[Wh] to
WP
+3
[Wh]
Active energy (Consumption), first cir-
cuit to third circuit
Active energy (Consumption) for each
of th
ree 1
P2W circuits
WP-[Wh] Active energy (Regeneration)
Active energy from start
of recording (Regenera-
tion)
WP-1[Wh] to WP-3[Wh]
Active energy (Regeneration), first cir-
cuit to third circuit
Active energy (Regeneration) for each
of th
ree 1P2W circuits
WQLAG[varh] Reactive energy (Lag)
Reactive energy from
start of recording (Lag)
WQLAG1[varh] to
WQLAG3[varh]
Reactive energy (Lag) , first circuit to
thir
d circuit
Reactive
energy (Lag) for each of
thr
ee 1P2W cir
cuits
WQLEAD[varh] Reactive energy (Lead)
Reactive energy from
st
art
of recording (Lead)
WQLEAD1[varh] to
WQLEAD3[varh]
Reactive energy (Lead), first circuit to
thir
d circuit
Reactive
energy (Lead) for each of
thr
ee 1P2W cir
cuits
WP+dem[Wh]
Active power demand quantity (Con-
sumption)
Active energy (Con-
sumption) for each inter-
val time
WP+dem1[Wh] to
WP+dem3[Wh]
Active power demand quantity (Con-
sumption), first circuit to third circuit
Active power demand quantity (Con-
sumption) for each of three 1P2W cir-
cuits
Parameter Parameter name Description
