10.5 LAN Communications
159
Chapter 10 Using Communications (USB/LAN)
10
Preparation items(provide either of the following)
When connecting the instrument to an existing network
(when connecting the instrument to a hub)
Model 9642 LAN Cable (optional)
A 100Base-TX straight cable (up to 100 m
in length, commercially available)
If using a 10Base network, a 10Base-T ca-
ble can be used.
1
Connect the LAN cable to the instrument’s LAN interface.
2
Connect the LAN cable to the hub’s 100Base-TX connector.
To Next Page
