12.2 Basic Specifications
179
Chapter 12 Specifications
12
Display range
Voltage : 5 V to 1,000 V; separate warning displayed when over-
range
Zero-suppression processing forces volta
ge RMS values
of less than 5 V to be displayed as 0 V.
If the voltage RMS value is 0 V, a harmonic voltage of 0 is
used for all orders. (PW336
0-21 only)
Current : 0.4% to 130% of range
Separate warning displayed when over-range or over-
peak.
Zero-suppression processing forces current R
MS values
of less than
0.4% to be displayed as 0 A.
If the harmonic current is 0 A, a harmonic current of 0 is
used for all orders. (PW336
0-21 only)
Power : 0% to 130% of range (zer
o-suppression is triggered when
the voltage RMS value or current RMS value is 0)
If the voltage RMS value or current RMS value is 0, a har-
monic active power and harmonic reactive power of 0 are
used for all orders. (PW3360-21 only)
Effective
measuring
range
Voltage : 90 V to 780 V; peak: ±1,400 V
Current : 5% to 110% of range; pe
ak: ±400% of range
However, maximum range is 200%.
Power : 5% to 110% of range
Frequency : 45 Hz to 66 Hz
Measurement
items
Voltage RMS, current RMS, voltage fundamental wave value, current
fundamental wave value, voltage fundamental wave phase angle,
current fundamental wave phase angle, frequency (U1), voltage
waveform peak (absolute value), current waveform peak (absolute
value), active power, reactive power (with lag/lead display), apparent
power, power factor (with lag/lead display) or displacement power
factor (with lag/lead display), active energy (consumption, regenera-
tion), reactive energy (lag, lead), energy cost displa
y
, active power
demand quantity (consumption, regeneration), reactive power
demand quantity (lag, lead), active power demand value (consump-
tion, regeneration), reactive power demand value (lag, lead), power
facto
r
demand, pulse input, harmonic voltage level, harmonic current
level, harmonic power level, content percentage, phase angle, total
harmonic distortion (THD-F or THD-R) (PW3360-21 only)
Measurement specifications
