12.4 Functional Specifications
191
Chapter 12 Specifications
12
Setting screen
Wiring
1P2W/1P2W×2/1P2W×3/
1P3W/1P3W+I/1P3W1U/1P3W1U+I/
3P3W2M/3P3W2M+I/3P3W3M/3P4W/
Current only (I)/Current only (I)×2/Current only (I)×3
Frequency
50Hz/60Hz
If there is voltage input and the frequency setting is wrong, displays
an error and changes the frequency setting.
Clamp sensor
Load current: Model 9660/9661/9694/9669/9695-02/9695-03/
CT9667(500A)/CT9667(5000A)
Leakage current: Model 9657-10/9675
Current range
Load current
Model 9660, 9695-03 (1mV/A): 5.0000/10.000/50.000/100.00 A
Model 9661 (1mV/A): 5.0000/10.000/50.000
/100.00/500.00 A
Model 9669 (0.5mV/A): 100.00/200.00/1.0000k A
Model 9694 (10 mV/A): 500.00m/1.0000/5.0000/10.000/50.000 A
Model 9695-02 (10mV/A): 500.00m/1.0000/5.0000/10.000/50.000 A
Model CT9667 500A range (1mV/A): 50.00
0/100.00/500.00 A
Model CT9667 5000A range (0.1mV/A): 500.00/1.000
0 k/5.0000k A
Leakage current
Model 9657-10, 9675 (100mV/A): 50.000m/100.00m/500.00m/1.0000/5.0000 A
CT ratio
User-specified: 0.01 to 9999.99
Selected: 1/40/60/80/120/160/200/240/300/400/600/800/1200
Voltage range 600 V fixed
VT (PT) ratio
User-specified: 0.01 to 9999.99
Selected: 1/60/100/200/300/600/700/1000/2000/2500/5000
PF/Q/S
calculation
selection
RMS calculation / fundamental wave calculation
Energy cost
Unit cost: 0.00000 to 99999.9/kWh
Currency: 3 user-specified alphanumeric characters
THD calcula-
tion selection
(PW3360-21
only)
THD-F/THD-R
Remaining
save time
Calculated and displayed based on the amount of space remaining
on the SD memory card or in the internal memory, the save interval,
and the save items. Also updated during time-series measurement.
Save
destination
SD memory card / internal memory (capacity: approx. 320 KB)
