12.4 Functional Specifications
198
External interface specifications
SD memory card interface
Slot SD standard compliant x 1
Compatible
card
SD memory card/ SDHC memory card (Use only HIOKI-approved
SD memory card)
Format SD memory card format
Supported
memory
capacity
SD memory card: up to 2GB/ SDHC memory card: up to 32GB
Saved data Settings data, measurement data, screen data, and waveform data
LAN interface
Connector RJ-45 connector x 1
Electrical
specifications
IEEE802.3 compliant
Transmission
method
10BASE-T/100BASE-TX
Protocol TCP/IP
Functions
HTTP server function
Capture of settings and measurement data and data downloading
wi
th a communications application
USB interface
Method
USB Ver.2.0 (full speed, high speed)
Mass storage class, virtual COM (CDC)
Connection
destination
Computer
Supported
operating
systems
WindowsXP/ WindowsVista (32bit)/ Windows7 (32/64bit)
/ Window8 (32/64bit)
With latest service packs applied
Functions
When connected to a computer, the SD memory card and internal
memory will be recognized as removable disks, allowing capture of
settings and measurement data and data downloading with a com-
munications application.
