3.3 Connecting the Voltage Cords
48
The voltage cords connection
1
Attach the alligator clip or magnet
adapter to the end of the voltage
cord.
2
Insert the voltage cords into the
voltage input terminals while
checking the [WIR, DIAG] screen.
Magnet
adapter
or
Alligator clip
Insert plugs all the way in.
To Next Page
