7.1 Inserting and Removing Storage Media
134
Insert and remove CF cards and USB flash drives as follows.
7.1 Inserting and Removing Storage Media
CF card
To insert a CF card
Open the CF card slot cover, and with the mark pointing toward the screen,
insert the card in the direction shown by the arrow as far as it will go.
To remove a CF card
Open the CF card slot cover, press the eject button so that it pops out, then press it
again to eject the CF card.
USB flash drive
Insert a USB flash drive in the USB port on the front of the instrument (and just pull it
out to remove).
• Do not insert any device other than a USB flash drive.
• Not all commercially available USB flash drives are compatible.
