4.6 Viewing Noise Measurement Values (FFT Function)
85
4
Chapter 4 Viewing Measurement Values
Set the FFT sampling rate and number of points according to the frequency of the noise to be analyzed.
These settings are on the [Calc] page of the Setting screen.
Sampling can be selected at the [Noise] setting on the [Wave + Noise] page of the Measurement screen.
How to display, see "Displaying Noise" (p. 83).
4.6.2 Setting the Sampling Frequency and Points
Changing Sampling on the Measurement Screen
Select the item
Display the
[
Calc] page
Select with the F keys
See Screen display procedure:"Displaying
Noise" (p. 83)
Select the item
Enter
Selects from the pull-down
menu
Cancel
Displays the pull-down
menu
