3.10 Setting the Current Sensors
38
If a CT7044, CT7045, CT7046, CT7642, or CT7742 large current sensor has been connected to the
instrument's current input terminal via the CT9920 Conversion Cable, set the model or output rate of the
current sensor in use.
3.10 Setting the Current Sensors
Selecting the current sensors in use
Display the
[Sensor] page
Select with the F keys
Select the item to
display
Select a [Current sensor] for
the channel being set.
If a high-precision sensor that does not require the CT9920 Conversion Cable has
been connected directly to one of the instrument’s current input terminals, there is no
need to select the current sensor since the instrument will detect it automatically.
