Network Load Control
152
8.4
QoS/Priority
Basic Configuration
Release
6.0
07/2010
Always assign the DSCP priority to received IP data
packets globally
Configuring Layer 2 management priority
Configure the VLAN ports to which the device sends management
packets as a member of the VLAN that sends data packets with a tag
(see on page 158 “Examples of VLANs“).
Class of Service Trust Mode: IP DSCP
Non-IP Traffic Class: 2
Select the QoS/Priority:Global dialog.
Select trustIPDSCP in the "Trust Mode" line.
enable
Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
classofservice trust ip-
dscp
Assign the "trust ip-dscp" mode globally.
exit Switch to the Configuration mode.
exit Switch to the privileged EXEC mode.
show classofservice trust Display the trust mode.
Class of Service Trust Mode: IP DSCP
Select the QoS/Priority:Global dialog.
In the line VLAN priority for management packets you enter
the value of the VLAN priority.
enable Switch to the Privileged EXEC mode.
network priority dot1p-vlan
7
Assign the value 7 to the management priority so
that management packets with the highest priority
are sent.
exit Switch to the privileged EXEC mode.
show network Displays the management VLAN priority.
