Hirschmann RS20 User Manual

Network Load Control
Basic Configuration
Release 6.0 07/2010
8.4 QoS/Priority
151
 Assigning the traffic class to a DSCP
 Always assign the DSCP priority to received IP data
packets per interface (PowerMICE, MACH 104, MACH 1040
and MACH 4000)
exit Switch to the privileged EXEC mode.
show classofservice trust
1/1
Display the trust mode on interface 1/1.
Class of Service Trust Mode: Untrusted
Untrusted Traffic Class: 4
 Select the
QOS/Priority:IP DSCP Mapping dialog.
 In the "Traffic Class" column, enter the desired values.
enable Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
classofservice ip-dscp-
mapping cs1 1
Assign traffic class 1 to DSCP CS1.
show classofservice ip-dscp-mapping
IP DSCP Traffic Class
------------- -------------
0(be/cs0) 2
1 2
.
.
8(cs1) 1
.
enable Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
interface 6/1
classofservice trust ip-
dscp
Switch to the interface configuration mode of
interface 6/1. Assign the "trust ip-dscp" mode to the
interface.
exit Switch to the Configuration mode.
exit
Switch to the privileged EXEC mode.
show classofservice trust
6/1
Display the trust mode on interface 6/1.
