Hirschmann RS20 User Manual

Operation Diagnosis
202
9.8 Topology Discovery
Basic Configuration
Release 6.0 07/2010
If several devices are connected to one port, for example via a hub, the
table will contain one line for each connected device.
If
X devices with active topology discovery function and
X devices without active topology discovery function
are connected to a port, the topology table hides the devices without
active topology discovery.
If
X only devices without active topology discovery are connected to a
port, the table will contain one line for this port to represent all
devices. This line contains the number of connected devices.
MAC addresses of devices that the topology table hides for the sake
of clarity, are located in the address table (FDB), (see on page 122
“Entering Static Addresses“).

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
