4 Electrical wiring
152
SMGB0077 rev.0 - 01/2013
Control box terminal board
DX-Interface EXV-(2.0-10.0)E1
Terminal board 1
Terminal board 2
(*)
N O T E
(*) Packing gland for thermistor installation
