10 Servicing
352
SMGB0077 rev.0 - 01/2013
10.6.6 Removal of the oat switch
Nº Part
1 Float switch position
N O T E
Todisconnectandremovetheoatswitch,previouslyseethe
chapter corresponding to the wiring diagrams in this Manual.
Remove the drain pump support screws and remove it.
Loosen the screws securing the oat switch to the support.
Loosen the resin nut securing the oat switch and remove it.
N O T E
The torque value of the resin nut is 0.3 - 0.4 Nm. If the torque
value is higher, the nut will be damaged.
Nº Part
1 Float switch
10.6.7 Removal of the air lter
Nº Part
1 Air lter
2 Screws
3 Air lter xture bar
To Next Page
