10.8.5 Removal of the oat switch
Nº Part
1 Float switch position
N O T E
Todisconnectandremovetheoatswitch,previouslyseethe
chapter corresponding to the wiring diagrams in this Manual.
Remove the necessary covers to access the oat switch.
Loosen the screws securing the oat switch to the support.
N O T E
The torque value of the resin nut is 0.3 - 0.4 Nm. If the torque
value is higher, the nut will be damaged.
Nº Part
1 Float switch
Loosen the resin nut securing the oat switch and remove it.
