2.1 RCI - 4-way cassette
2.1.1 Accessories supplied with the unit
Check that the following accessories are supplied with the unit.
N O T E
Please contact your HITACHI distributor if any of the accessories has not been supplied with the unit.

RCI-FSN3 indoor unit
Accessory Quantity Purpose
Pattern (Carton Board)
1
For adjusting space of false ceiling opening
and position of the unit
Checking pattern
(Cut out from the carton board)
1
Cross recessed head screws (M6)
4 For tting paper pattern
Washer with insulation (M10) 4
For unit installation
Washer (M10)
4
Drain hose 1
For drain hose connection
Wire clamp 1
Pipe insulation
1
For refrigerant piping connection
Pipe insulation
1
Cord band
2
For xing remote control switch wiring, lo-
uver sensor and insulation of piping
Cord band 6
Insulation (5Tx50x200)
1 For covering wiring connection
Insulation (5Tx100x200) 1
For covering drain connection
Insulation (5Tx25x500)
1

RCI-FSN3Ei indoor unit
Accessory Quantity Purpose
Pattern (Carton board)
1
For adjusting space of false ceiling opening and
position of the unit
Cross recessed head screws
4 For tting paper pattern
Washer with insulation
4
For unit installation
Washer (M10)
4
