Hitachi RPI-4.0FSN4E - Removal of the Electrical Box Cover

10 Servicing
317
10
SMGB0077 rev.0 - 01/2013
10.2.3 Removal of the electrical box cover
Nº Part
1 Screws
2 Electrical box cover
The electrical box can be removed by opening the air inlet grille.
Remove the two set screws from the electrical box cover and
remove it.
