10 Servicing
348
SMGB0077 rev.0 - 01/2013
10.6 RPI-(0.8-6.0)FSN4E
10.6.1 Removal of the electrical box
Nº Part
1 Location of the electrical box cover
RPI-(0.8-1.5)FSN4E RPI-(2.0-6.0)FSN4E
1
1
Nº Part
1 Set screw
2 Terminal board
3 Transformer
4 PCB
RPI-(0.8-1.5)FSN4E RPI-(2.0-6.01)FSN4E
1
1
2
3
4
