10 Servicing
316
SMGB0077 rev.0 - 01/2013
10.2 RCI - 4-way cassette (1.0-6.0)FSN3Ei
10.2.1 Removal of the long-lasting air lter
Nº Part
1 Button
2 Air inlet grille
The long-lasting lter is located inside the air inlet grille.
Press the buttons in the direction indicated by the arrows and open
the air inlet grille.
Remove the lter from the grille by holding onto the lower part of
the grille and the lter and detaching the blocked part.
10.2.2 Removal of the air inlet grille
Nº Part
1 Fan
2 Air inlet grille
3 Long-lasting lter
4 Chain
5 Hooks
Lift the grille approximately 30° and release the securing chain.
Remove the grille by sliding it upwards and forwards.
N O T E
If the chain is released and the grille angle is at 90°, the grille
cannot be removed.
