5 Control system
183
5
SMGB0077 rev.0 - 01/2013
Temp.: condenser temperature.
Identiîš¿er Name
MC Motor (for the compressor)
MIF Motor (for the indoor fan)
MOF1, 2 Motor (for the outdoor fan)
MS Motor (for the automatic louver)
MV Electronic expansion valve
CMC Magnetic compressor contactor
CH Crankcase heater
CT1 Current transformer
PSH High pressure switch
RVR 4-way valve
SVA, B, F Solenoid valve
PSC Control pressure switch
EHW Electric heater
MCU Microcomputer
