Number Part name Remarks
U02 Remote control swicth PC-P2HTE / PC-ART (optional)
U04A Fuse 0.5A for control circuit
U04B Fuse 5A for power source
U15B Thermistor THM2 air outlet
U15C Thermistor THM3 freeze protection (Liquid)
U15D Thermistor THM5 gas
U21 Expansion valve —
U31 Air îš¿lter For air panel P-N23WAM
U34 Air grille For air panel P-N23WAM
U35A Knob For air panel P-N23WAM
U35B Knob For air panel P-N23WAM
U36 Runner —
U41A/B Heat exchanger Assembly
U65 Spacer For PCB
U71A Fan motor 52W
U71B Fan motor Discharge mechanism
U71C AS motor For air panel P-N23WAM
U82 Transformer —
U85A Printed circuit board Main
U85B Printed circuit board Power supply
U85B Printed circuit board Noise protection
U87 Float switch —
