Page #283 background imageLoading...
Page #283 background image
9 Spare parts
271
9
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
U04 Fuse 5A for the control circuit
U14 Capacitor 4/5MF 440VAC
U15A Thermistor THM1 thermistor for air inlet
U15B Thermistor THM2 thermistor for air outlet
U15C Thermistor THM3 thermistor, protection against liquid freezing
U15D Thermistor THM5 thermistor for gas
U21 Expansion valve —
U31 Air îš¿lter For air panel P-N23DWA
U34 Air grille For air panel P-N23DWA (with air îš¿lter)
U36 Fan —
U41 Heat exchanger —
U65 Plastic material —
U71A Motor 35W fan
U71B Motor For the discharge drain mechanism
U71C Motor For the P-N23DWA motor rotation assembly
U82 Transformer —
U85A Printed circuit board Main PCB
U85B Printed circuit board Noise protection
U85C Printed circuit board Modulation band pulse
U87 Float sensor —
