Number Part name Remarks
1 Terminal Board -
2 Remote Control SW PC-ART (Optional)
3 Electrical Box Assembly (Components + Harness)
4 Capacitor Assy. -
5 Thermistor For Liquid Pipe
6 Thermistor For Gas Pipe
7 Thermistor For Inlet Air
8 Thermistor For Outlet Air
9 Expansion Valve (Without Coil)
10 Expansion Valve Coil -
11 Filter -
12 Runner -
13 Fan Casing -
14 Heat Exchanger Assembly
15 Spacer For PCB îš¿xing
16 Drain Pump Discharge Mechanism
17 Fan Motor -
18 Fan Assy. Assembly (Motor + Stay + Runners + Casings)
19 PCB1 Control PCB
20 PCB2 Power PCB
21 Float Switch -
22 Drain Pan Assembly
