9 Spare parts
287
9
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
1 Heat exchanger -
2 Drain cap -
3 Expansion valve Only for RPK-(0.8/1.0)FSN3M
4 EXPV motor Only for RPK-(0.8/1.0)FSN3M
5 Thermistor For air inlet (THM1)
6 Thermistor For air outlet (THM2)
7 Thermistor For freeze protection (THM3)
8 Thermistor For gas line (THM5)
9 Fan motor DC, 38W
10 Motor clamp -
11 Fan -
12 Bearing -
13 Bottom base -
14 Corner cover -
15 Drain hose -
16 Pipe cover -
17 Cabinet panel assy -
18 Filter -
19 Drain pan assy -
20 Plate -
21 AS Motor for Auto Swing Louver
22 PCB PI-121-S for Control
23 PCB for Switch
24 PCB for Receiver with Indicator
25 Terminal board for Power Source Circuit
26 Terminal board for Control Circuit
27 Fuse Fuse on PI-121-S, 5A
28 Flare nut f12.7
29 Screw cap -
