9 Spare parts
291
9
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
1 Heat Exchanger -
2 Drain Cap -
3 Expansion Valve -
4 EXPV Motor For expansion valve
5 Thermistor For air inlet (THM1)
6 Thermistor For air outlet (THM2)
7 Thermistor For freeze protection (THM3)
8 Thermistor For gas line (THM5)
9 Fan Motor DC, 38W
10 Motor Clamp -
11 Fan -
12 Bearing -
13 Cabinet Assy -
14 Corner Cover -
15 Pipe Fixing Plate -
16 Drain Hose -
17 Pipe Cover -
18 Cabinet Panel Assy -
19 Filter -
20 Receiver Cover -
21 Drain Pan Assy -
22 Plate -
23 AS Motor for Auto Swing Louver
24 PCB-S PI-121-S for Control
25 PCB-S for Receiver
26 PCB-S for Switch
27 PCB-S for Indicator
28 Terminal Board for Power Source Circuit
29 Terminal Board for Control Circuit
30 Fuse Fuse on PI-121-S, 5A
31 Horizontal Blade -
32 Screw Cap -
33 Flare Nut f15.88
