9 Spare parts
297
9
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
1 Duct Connector Plastic material
2 Duct Connection Sealing Strip For Duct Connector
3 Damper Motor AC Motor for Damper
4 Exchanger Guide Gasket -
5 Fan Assy Fan Cover
6 Air Filter Inlet & Outlet Air
7 Heat Exchanger
Celluloid Heat Exchanger (Aluminium HE for KPI-XXX-
H3E)
8 Fan Service Cover -
9 Heat Exchanger Cover Clamp -
10 E-Box Cover -
11 Fuse 2/4 A (6x32) - Fan Protection
12 Transformer Main Transformer
13 Printed Circuit Board (PI073) -
14 Printed Circuit Board -
15 Terminal Board -
16 Fuse Holder -
17 Thermistor Blue Socket
18 Thermistor Red Socket
19 Spacer Main PCB Holder
20 Push Spacer -
21 Electrical Box -
22 Dx-coil service cover -
23 Float switch -
24 Thermistor Blue Socket (Freeze)
25 Thermistor Yellow Socket (Gas)
26 Dx-Coil Module -
27 Remote Control -
