9 Spare parts
300
SMGB0077 rev.0 - 01/2013
Number Part name Remarks
1 E-BOX EXP. VALVE KIT
2 E-BOX EXP. VALVE KIT
3 PACKING GLAND
4 PACKING GLAND NUT
5 PRINTED CIRCUIT BOARD AUX PCB
6 SPACER For PCB Fixing
7 TERMINAL BOARD
8 TERMINAL BOARD
9 TRANSFORMER
10 PUSH SPACER For PCB Fixing
11 THERMISTOR THM3: For liquid Pipe; Black socket
12 THERMISTOR THM5: For Gas Pipe; Yellow socket
13 THERMISTOR THM1: For Inlet Air; Blue socket
14 THERMISTOR THM2: For Outlet Air; Red socket
15 PACKING GLAND WASHER
16 COVER
17 E-BOX FINAL ASSY Assembly (Components + Harness)
18 EXP. VALVE ASSY Assembly
19 PRINTED CIRCUIT BOARD
20 EXP VALVE KIT ASSY Assy (Valve stay + EXV Kit)
To Next Page
