10 Servicing
330
SMGB0077 rev.0 - 01/2013
Remove the ange from the hose and remove the drain hose.
Remove the earthing wiring screw.
Hold the drain mechanism and remove the screw from the
mechanism securing plate.
Remove the mechanism with the securing plate.
N O T E
When installing, t thedrain hose asfar aspossible in the
pump.
