Addressable SLC Devices
IDP-Monitor
Standby/Alarm: .375 mA mA mA
IDP-Minimon
mA mA
IDP-Pull-SA/IDP-Pull-DA
mA mA
IDP-Monitor-2
Standby/Alarm: .75 mA mA mA
IDP-Monitor-10
Standby/Alarm: 3.5 mA mA mA
IDP-Control
SLC Standby: 375 mA
Alarm: .375 mA
mA
mA
Aux.
Power
Standby: 1.7 mA mA
Alarm: 7 mA mA
IDP-Control-6
SLC Standby: 2.25 mA
Alarm: 2.25 mA
mA
mA
Aux. Pwr Standby: 8 mA
Alarm: 20 mA
mA
mA
IDP-Relay
Standby/Alarm: .255 mA mA mA
IDP-Relay-6
Standby/Alarm: 1.45 mA mA mA
IDP-RelayMon-2
Standby: 1.3 mA mA
Alarm: 24 mA mA
IDP-Zone
Aux Pwr Standby: 12 mA mA
Alarm: 90 mA mA
SLC Standby/Alarm: 2 mA mA mA
IDP-Zone-6
Aux Pwr Standby: 70 mA mA
Alarm: per zone 90 mA mA
Alarm: Total with all 6
circuits active 540 mA
mA
SLC Standby/Alarm: 2 mA mA mA
SLC Accessories
B200SR/IV Sounder Base
Aux Pwr Standby: .5 mA mA
Alarm: 35 mA mA
SLC Standby .3 mA mA
B200S/IV Intelligent Sounder Base
Aux Pwr Standby: .5 mA mA
Alarm: (high vol) 35 mA mA
SLC Standby .3 mA mA
B200SR-LF/IV Low Frequency Sounder
Base
Aux Pwr Standby: 1 mA mA
Alarm: 125 mA mA
B200S-LF/IV Low Frequency Sounder
Base
Aux Pwr Standby .55 mA mA
Alarm (high vol) 140 mA mA
SLC Standby .30 mA mA
B224RB/IV Relay Base
Standby/Alarm: .5 mA mA mA
RTS151/151 KEY
Alarm: 7.5 mA
mA
RA100Z
Alarm: 10 mA
mA
SLC Isolator Devices
IDP-ISO (Isolator Module)
(100 max.) Standby/Alarm: .45 mA mA mA
B224BI/IV Isolator Base
Standby/Alarm: .5 mA
Accessories Modules
6815 SLC Loop Expander
(63 max.) Standby/Alarm: 78 mA mA mA
RA-2000 Remote LCD Annunciator
(16 max.) Standby: 25 mA mA
Alarm: 50 mA mA
RA-1000 Remote LCD Annunciator
Standby: 20 mA mA
Alarm: 25 mA mA
RA-100 Remote LCD Annunciator
Standby: 20 mA mA
Alarm: 25 mA mA
Device
Number of
Devices
Current per Device
Standby
Current
Alarm
Current
Table 3.2 Current Draw Worksheet for IDP SLC Devices
