161 IFP-300 / IFP-300ECS Manual P/N LS10145-001SK-E:B 12/18/2017
Section 12: Reporting
This section lists receivers that are compatible with this control panel, and the reporting codes sent by the control panel for SIA and Con-
tact ID formats.
12.1 Receivers Compatible with the Control Panel
“: Receivers Compatible with the Control Panel” on page 161 shows receivers compatible with the control panel. This table includes, but
is not limited to the Central stations listed below.
Manufacturer Model Format
Honeywell Model 9800 SIA and Contact ID
Model 9000 (SIA formats) SIA
Honeywell Security AlarmNet 7810-ir IP and Cellular Receiver,
Contact ID only
Ademco MX8000 SIA and Contact ID
Ademco Model 685 (Contact ID ) Contact ID
Sur-Gard SG-MLR2-DG (V. 1.64 or higher) SIA and Contact ID
Osborne Hoffman Quickalert SIA and Contact ID
Table 12.1 Receivers Compatible with the Control Panel
SIA Reporting Format
Contact ID Reporting Format
SIA pi Modifier SIA
Event Description Module
ID # (If
Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN -
panel ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
System Events System Events are reported when either “Report by Point” or Report by Zone is selected
AC power low trouble AT 0 ATNN000000 1 301 00 000
AC power low trouble restore AR 0 ARNN000000 3 301 00 000
Auto dialer test communications
trouble line 1
YC 1 YCNN000001 1 350 Receiver # 001
Auto dialer test communications
trouble line 1 restore
YK 1 YKNN000001 3 350 Receiver # 001
Auto dialer test communications
trouble line 2
YC 2 YCNN000002 1 350 Receiver # 002
Auto dialer test communications
trouble line 2 restore
YK 2 YKNN000002 3 350 Receiver # 002
Automatic test normal RP 0 RPNN000000 1 602 00 000
Automatic test off normal RY 0 RYNN000000 1 608 00 000
Battery voltage trouble YT Exp. ID YTNNXX0000 1 302 Exp. ID 000
Battery voltage trouble restore YR Exp. ID YRNNXX0000 3 302 Exp. ID 000
Date changed event JD 0 JDNN000000 1 625 00 000
ECS Reset OR 1 ORNN000001 1 401 00 001
Emergency System Overridden QS 0 QSNN000000 1 244 00 000
Emergency System Overridden
Restore
QR 0 QRNN000000 3 244 00 000
Fire drill has begun FI 0 FINN000000 1 604 00 000
Fire drill has ended FK 0 FKNN000000 3 604 00 000
F1 Mapping Inhibited FT 2001 FTNN002001 1 570 00 001
F1 Mapping Inhibited Restoral FJ 2001 FJNN002001 3 570 00 001
F2 Mapping Inhibited FT 2002 FTNN002002 1 570 00 002
F2 Mapping Inhibited Restoral FJ 2002 FJNN002002 3 570 00 002
F3 Mapping Inhibited FT 2003 FTNN002003 1 570 00 003
F3 Mapping Inhibited Restoral FJ 2003 FJNN002003 3 570 00 003
Table 12.3 : Report Formats Table
