155 IFP-300 / IFP-300ECS Manual P/N LS10145-001SK-E:B 12/18/2017
2. Both fire and the emergency systems are active and the highest priority active fire event is programmed to be of higher priority than
the highest priority active emergency event.
3. Only the fire system is active, the user has gained ECS Control, and custom ECS event is a lower priority than the fire alarm.
An emergency page can occur when:
1. Only the emergency system is active and the user has gained ECS Control.
2. Both fire and the emergency systems are active and the highest priority active emergency event is programmed to be of higher
priority than the highest priority active fire event and the user has gained ECS Control.
3. Only fire system is active, the Emergency LOC Alarm priority is higher than the active fire system event and the user has gained
ECS Control.
• This will trigger the ECS system and enable mapping for 'Mic Triggered ECS Alarm' and 'General ECS Alarm'.
Paging
If there are no active emergency or fire system events, the microphone at an LOC can be used for paging by following these steps:
1. Push the PTT (Push To Talk) button on the microphone.
2. Use the Select Keys on the LOC to toggle the output areas to page to with the microphone (illuminates the green LEDs).
3. Speak into the microphone.
4. Release PTT button when finished.
11.8 Recording Custom Messages
The ECS-Series VCM or NVCM come with 15 recordable message slots. Message 1-15 can be recorded from the microphone, Aux
Input or by using the Message Manager utility of HFSS Honeywell Fire Software Suite. All messages can be a maximum of one minute.
NOTE: If fire and emergency systems are active and emergency system is of a higher priority, a fire page is NOT allowed. An LOC must gain
ECS Control in order to do any live voice.
NOTE: The Ready to Talk LED will illuminate after an output area has been activated.
