IFP-300 / IFP-300ECS Manual P/N LS10145-001SK-E:B 12/18/2017 2
• Supports up to eight ECS-50W, ECS-125W, ECS-INT50W, or ECS-DUAL50W Addressable Amplifiers for a maximum of 1000
watts per system
• Support for dual channel and backup audio using the ECS-DUAL50W amplifier and ECS-50WBU back-up amplifier.
1.1.5 Terms Used in this Manual
The following terminology is used with the IFP-300 / IFP-300ECS system:
1.2 Compatible Products
The chart below lists the products available from Honeywell for use with the IFP-300.
Term Description
SLC Signaling Line Circuit
Module The term module is used for all hardware devices except for SLC addressable devices and
notification appliances. This includes the IFP-300 panel itself.
Input Point An addressable sensing device, such as a smoke or heat detector or a contact monitor
device.
Input Zone A protected area made up of input points.
Output Point
(or Output Circuit)
A notification point or circuit for notification appliances. Relay circuits and auxiliary power
circuits are also considered output points.
Output Group (OPG) A group of output points. Operating characteristics are common to all output points in the
group.
Output (or “Cadence”) Pattern The pattern that the output will use, for example, Constant, March Code, ANSI 3.41. Applies
to zones and special system events. See “Cadence Patterns” on page 199 for additional
information.
Mapping Mapping is the process of specifying which outputs are activated when certain events occur
in the system. Section 8.2 explains mapping in detail.
ECS Emergency Communication System
Networking Up to 32 panels can be networked.
Network System Consist of any combination of 32 panels of these model numbers: IFP-75, IFP-300, IFP-
300ECS, IFP-2100 or IFP-2100ECS.
SWIFT Smart Wireless Integrated Fire Technology
Type of Device Model Description
IDP Addressable SLC Devices See Section 7.1 for a list of compatible devices
SK Addressable SLC Devices See Section 7.2 for a list of compatible devices
SD Addressable SLC Devices See Section 7.3 for a list of compatible devices
SWIFT Wireless SLC Devices See Section 7.4 for a list of compatible devices
Other Modules
5824 Serial/Parallel
Printer Interface Module
Allows a printer to be attached for the system for on-site event logging. Four
maximum per system.
5815XL (Rev H or above)
SLC Expander
Allows up to 127 SD devices to be added to the system. The number of
5815XLs that can be added to the system is limited only by the maximum
number of SBUS devices. However the maximum point count is limited to 254
per panel. Supports SD protocol devices only.
6815 SLC Expander Supports System Sensor Devices (IDP or SK) only. Each 6815 supports up to
159 IDP or SK sensors and 159 IDP or SK modules. Maximum point count is
300 per panel.
RPS-1000 (Rev F or
higher) Intelligent Power
Supply
Provides additional power, six Flexput™
circuits, and two Form C relays.
RPS-1000s and 5496s can be
used in any combination, up to
a total of 16 on one system
5496 (Rev F or above)
NAC Expander
Add 4 Notification/Auxiliary power circuits
with each 5496 Intelligent Power Module
RA-2000 Remote LCD
Annunciator
4x 40 Remote LCD annunciator, can be used in any combination, up to a total
of 16 devices on one panel.
RA-100 Remote LCD
Annunciator
4 x 20 Remote LCD annunciator, can be used in any combination, up to a total
of 16 devices on one panel.
Table 1.1 IFP-300 Compatible Products
