78
Galaxy 2 Series Installation Manual
44 Abort (Latch)
The ABORT output is activated when a valid code is entered to unset the system following a signalled intruder
alarm.
45 Unset (Pulse)
The Unset output is activated each time the system (or group) is unset.
51 Link (Reflex)
Activates when link zone is activated see 52.1
66 RF Jam (Latch)
The RF Jam output is activated whenever any of the RF RIO’s configured onto the system detect a significant
level of interference to cause radio jamming.
67 RF Supervision Fail (Reflex)
The RF Supervision Fail output is activated whenever there is a supervision failure from any one of the
supervised RF detectors configured onto the system. That is, when the system has received no signals (includ-
ing periodic check-in signals) whatsoever, from a particular detector within the programmed supervision
period.
68 Assistance (Latch)
Keypad assistance hot key activation or assistance zone.
70 Any Set (Reflex)
Activated when system is Full Set, Part Set or Night Set.
71 Bell Fail (Reflex)
Activates when bell fail zone is activated see Option 52.1
72 RF TX Low Battery (Reflex)
The RF TX Low Battery output is activated whenever an RF detector sends a low battery condition to an
RF receiver.
53 - Outputs (cont’d)
